Java wrapper of GDAL

This blog is about to become a tech blog in addition to everything else. This is for my benefit and the benefit of all the other intrepid voyagers journeying through the vastness of the techscape.


This post describes the setup of the Java bindings of GDAL. The basic idea was that I wanted access to other image formats, in particular ENVI, without writing a bunch of code to slice and dice the binary blobs in which ENVI stores image data. There are a lot of ways to wrap the GDAL binaries from scratch. For some examples, see here: http://trac.osgeo.org/gdal/wiki/GdalOgrInJava


Call it laziness, but I just did not want to deal with SWIG and having to re-compile everything. I suspected there is an easier way and there is. Good tech samaritan Tamas Szekeres maintains this list of pre-compiled binaries, including wrappers: http://vbkto.dyndns.org/sdk/


So I downloaded this one, for my Windows XP 32-bit operating system: release-1600-gdal-1-8-mapserver-5-6 which is compiled with Microsoft Visual C++ 2010. In the install directory is a GDAL/java/gdal.jar file. I would like to make use of this from within the Eclipse IDE. So I add gdal.jar to the class path and try to gdal.AllRegister(); But I get an exception like:


Native library load failed. java.lang.UnsatisfiedLinkError: C:\Program Files\GDAL\gdaljni.dll: Can't find dependent libraries


So I add the following to the VM arguments:

-Djava.library.path="C:/Program Files/GDAL"

This got me a little further but still threw an UnsatisfiedLinkError. Tamas suggested that I download the Microsoft Visual C++ 2010 Redistributable Package: http://www.microsoft.com/downloads/en/details.aspx?FamilyID=a7b7a05e-6de6-4d3a-a423-37bf0912db84


Once this was installed, gdal.AllRegister() runs without an exception, even if I remove the virtual machine argument. The GDAL test code also runs (GDALtest.java, GDALTestIO.java) no problem (given the data types that are checked in the code). I have now made a similar installation on a Windows 7 64-bit OS that works. However, I did discover that if GeoTools 2.7 is installed (with imageio-ext 1.0.6), GDAL and GeoTools will not play well together. As soon as I took GeoTools off the classpath, everything worked fine. Otherwise, I got an UnsatisfiedLinkError. Out of superstition, I also added the location of the GDAL binaries to the system "path" variable, just in case windows starts hunting around for something.


The other thing that I have experienced on both XP and Windows 7 is that the JNI wrapper broke, possibly after a recent update. After some gnashing of teeth, a reinstallation of either the VC++ redistributable or GDAL, everything started working again.
